Wireless Transmission Suite

• Wi-Fi Standard IEEE 802.11ac
• Frequency U-NII-1(5.15 ~ 5.25GHz), U-NII-2A(5. 25 ~ 5.35GHz)
• U-NII-2C(5.47 ~ 5.725GHz), U-NII-3(5.725 ~ 5.85GHz)
• Transmission Distance Maximum 1,500m (5,000 ft) on U-NII-3 band @ line of sight
• Transmission Power 250mW (24dBm)
• Antenna 3T x 3R
• Security 802.11i compatible signal protection by 128bit AES encryption

Wireless Transmission Suite

• Full HD sender (Ethernet or Wireless)
• H.264 (MPEG-4 Parts10 : AVC)
• Baseline Profile with level 4.2
• Zero delay (10ms), end-to-end (30ms), H.264 engine
• Transmission of 1080p60 3G-SDI over Wi-Fi
• Video formats of DTV Spec
• Security 802.11i compatible signal protection by 128bit AES encryption
